 FLOW RATE TO 94 LPM (25 GPM)
MAX INLET AIR PRESSURE = 6.9 BAR (100 PSI)- MAX DISCHARGE PRESSURE 20.7 BAR (300 PSI) WETTED HOUSINGS
(Water Chambers and Manifolds) | Material | Ship Wt | | Ductile Iron | 38 kg (84 lbs) |
NON-WETTED HOUSINGS | Description | Material | | Center Block | Aluminum | | Air Valve | Aluminum |
| Temperature Limits | | Operation | 225°F (107°C) | | Cleaning | 225°F (107°C) |
MAXIMUM SUCTION LIFT CAPABILITY
wet - 8.99m (29.5') dry - 2.77m (9.1') MAXIMUM DIAMETER SOLIDS
6.4 mm (1/4'') ELASTOMER OPTIONS | Material | Temperature Limits | | Wil-Flex™ | -40 (-40) to +107.2 (+225) °C (F°) |
|
